DataGrip

DataGrip supports querying both internal data and external data in PhoenixAI.

Prerequisites​

Make sure that your PhoenixAI cluster's inbound rules allow query requests from your DataGrip server.

Integration​

Create a data source in DataGrip. Note that you must select MySQL as the data source.

DataGrip - 1

DataGrip - 2

The parameters that you need to configure are described as follows:

  • Host: the endpoint of your PhoenixAI cluster.
  • Port: the query port of your PhoenixAI cluster, for example, 9030.
  • Authentication: the authentication method that you want to use. Select Username & Password.
  • User: the username that is used to log in to your PhoenixAI cluster, for example, admin.
  • Password: the password that is used to log in to your PhoenixAI cluster.
  • Database: the data source that you want to access in your PhoenixAI cluster. The value of this parameter is in the <catalog_name>.<database_name> format.
    • catalog_name: the name of the target catalog in your PhoenixAI cluster. Both internal and external catalogs are supported.
    • database_name: the name of the target database in your PhoenixAI cluster. Both internal and external databases are supported.
